The ends are burred and sharp, and require additional end treatment operations such as deburring or end rounding. Standard tolerance is +/- .030" to +/- .100".
Electrochemical cutting uses low voltage, high current electrical energy to effortlessly cut through the wire and tubing. Electrochemical cutting uses a specially designed cutting wheel (cathode), electrolyte solution, and electricity to effectively and precisely “cut" through wire and tubing (anode). By correctly adjusting the voltage, electrochemical cutting provides a burr-free cut on wire and hypotubing. Standard tolerance is +/- .005" to +/- .030" dependent on cut length.
Precision grinding is available on all inventory or customer supplied materials. Standard diameter is +/-.0002”, however tolerances as tight as +/-.00005” are possible.
Precision Wire EDM is available on all inventory or customer supplied materials. Standard diameter is +/-.0002”, however tolerances as tight as +/-.00002” are possible.
BENDING AND FORMING
Using a variety of methods including: CNC, rotary draw, fixed wiper and compression die. Size capacity ranges in diameter from .015″ to 1.5″ in.
Various custom finishing operations are available including passivation per ASTM-A967, ultrasonic cleaning, electropolishing, grit blasting, laser ablation, laser marking and more. Lead time varies depending on quantities and operations.
Several coatings with varying degrees of thickness such as PTFE, Polyimide, Polymer jacket and others. Custom-grind the base material to achieve the final coated diameter you need.
